suitable for indoors and outdoors from 20,000 to 30,000㎡ such as plant,warehouses, packing place and so on .It is small and maneuverable allowing the machine to fit easily through most doorways, aisles and congested spaces.
| Specification | |||
| Sweeping paths | 1250mm | Max working speed | 6Km/h |
| Productivity | 7500m2 /h | Max driving speed | 8Km/h |
| Main brush’s length | 600mm | Max climbing capacity | 20% |
Battery | 36V | Filter size | 8 Square meters |
| Continuous working time | 3-4h | Net weight | 400kg |
| Dustbin capacity | 100L | maintenance-free battery | Sealed Lead-Acid Battery |
| Side brush’s diameter | 500mm | Battery Size | cellnike 6-EVF-58Ah |
| Driving power | 1200W | Color | Green |
| Work power | 600+500+60+80*2w | Chassis | Iron |
| Turning radius(spot turn) | 1720mm | Packing size | 1.8m*1.2m*1.75m |
| Dimensions(L/W/H) | 1500×1250×1300mm | After packaging weight | 500kg |
T2 CHARACTERISTICS
Suitable for indoors and outdoors from 20,000 to 30,000㎡ such as plant,warehouses, packing place and so on .It is small and maneuverable allowing the machine to fit easily through most doorways, aisles and congested spaces.
1. Two side brushes, one main brush sweeping width of 1250mm.
2. Filter Size 8 squre meters.
3. Working Hour 3-4 hours.
4. Charging Time: 8-10 hours
Detail information and adxantages
Gemei
The shell is made of ABS material, which has high strength,aging resistance, corrosion resistance, anti fouling ability, easy to clean stains.
Gemei
Table 304 stainless steel panel, fresh. The United States Curtis power meter, low power consumption watchband protection is an important protection configuration for battery life. Schneider button, to reach the IP65 level, silver contact, longer service life.
Gemei
Driving power of 1.2 kilowatts, more able to adapt to the use of municipal sanitation high load environment.
Gemei
The shell is made of ABS material, which has high strength,aging resistance, corrosion resistance, anti fouling ability, easy to clean stainsThe battery line adopts 25 square GB flame retardant line, with overload protection device, and the battery pack to strengthen the floor, to reduce the impact and shock on the battery, the battery is connected with a protective paste..
Gemei
Seat with armrests and safety seats to increase operator comfort and safety.
Gemei
Integrated wiring harness, to achieve automotive TS16949 standards, wire to German standards, the use of flame-retardant wire.
Gemei
The filter core area of 8 square meters, the greater the filtration area, the more time to absorb the dust within the unit time, cleaning dust smaller, effectively prevent dust pollution of the two.
Gemei
We use good quality big power controller, with brake current recharge function, prolong the mileage, and electronic brake function, descent function, operation more safety.
